Noctua NH-D15 G2 LBC
Lab IDNCCLR00072
TypeAir
  • Testing Date: Jul 11, 2024
Scheme: THETA
AMD AM5THETA Platinum · Air · AMD AM5
No THETA levelIntel LGA1851
Aristeidis Bitziopoulos, Certification Body General Manager

THETA Cooler Performance

THETA is a Cybenetics performance rating. It is not part of our ISO/IEC 17065 certification schemes and is outside our accreditation.

Overall Performance (OP) = W × F / T, where W is the average CPU power at the EPS connectors (W), F the average CPU frequency (MHz) and T the average CPU temperature (°C). A cooler is rated on its measured OP at 30 dB(A) normalized noise output; a cooler that cannot reach 30 dB(A) is rated on its own measured 25 dB(A) point. Air and AIO coolers have separate ladders on each test platform.

Evaluated before Revision 2.0 of the Cooling Solutions Test Protocol: the THETA level was assigned from the published results measured under Revision 1.8 (20 minutes per noise level, 10-minute cool-down). The cooler was not measured again, and the earlier procedure is not identical to the procedure of Revision 2.0.

PlatformTHETA levelTest CPUMountRated atOverall Performance (OP)
AMD AM5THETA Platinum · Air · AMD AM5AMD Ryzen 9 7900X (AM5)Default30 dB(A)10,465
Intel LGA1851No THETA levelIntel Core Ultra 9 285K (LGA1851)Default--

General Information

Test Equipment

Noise Test Environment Hemi Anechoic Chamber with 6dB(A) noise floor
Sound Analyzer Bruel & Kjaer 2270 G4
Microphone Bruel & Kjaer Type 4955-A
Temperature Logger Picoscope TC-08
Climate Chamber Giant Force GTH-800-20-CP-AR
Testing Methodology Cybenetics Cooling Solutions Test Protocol

DUT Information

BrandNoctua
ModelNH-D15 G2 LBC
Lab IDNCCLR00072
Testing DateJul 11, 2024
EngineerAris Bitziopoulos

Climate Chamber

Noise Test EnvironmentHemi Anechoic Chamber with 6dB(A) noise floor
ManufacturerGiant Force
Model NumberGTH-800-20-CP-AR
Temperature Range-20℃ ~ +100℃
Humidity Range20% ~ 98% RH
Temperature/Humidity Constancy±0.2℃; ±2.5%RH
Temperature/Humidity Uniformity at center±0.5℃; ±4%RH
Internal Dimensions (WHD)100 x 100 x 80 cm
External Dimensions (WHD)145 x 190 x 135 cm
Net Weight (approximately)450 Kg
Heat-up Time (No load, no linear)(from 20°C to +100°C) 30min
Pull-down Time (No load, no linear)(from 20°C to -20°C) 50min
Cooling SystemAirtight compressor + evaporator fins + air-cooling condenser
Power Source3Φ AC 380V ±5%, 50Hz±1% 10KW
Based on StandardsISO 5801-2007, AMCA 210-0, ASHRAE 51-2007, IEC 61591-2005, GB/T 1236-200

AMD Test System

Mainboard Asus TUF GAMING X670E-PLUS
CPU AMD Ryzen 9 7900x
GPU Embedded
NVMe XPG GAMMIX S50 Lite 1TB
RAM XPG Lancer DDR5 (2 x 16GB) 6000MHz
Power Supply Seasonic Vertex 1200W
(Cybenetics Platinum)
CPU Cooler Device Under Test
Case Cooler Master Test Bench

Technical Specifications

Manufacturer (OEM)Noctua
ModelNH-D15 G2 LBC
Number of Fans2
Fan #1Noctua NF-A14x25r G2 (PPB)
Fan #2Noctua NF-A14x25r G2 (PPB)
TypeAir
Heatpipes8
Length152mm
Width150mm
Height168mm
Block MaterialCopper
Weight1525g
AMD Processors SupportAM5, AM4
Intel Processors SupportLGA1851/1700/1200/1156/1155/1151/1150

Noise Output and Fan Speed

Table

Fan SettingNoise (dB(A))Fan 1 (RPM)Fan 2 (RPM)
40%9.0596614
50%15.5777796
60%21.3922942
70%26.610601088
80%29.912041236
90%33.313541388
100%36.614941536

Graphs

Noise Output vs Fan SettingdB(A) [lower is better]Noise Output vs Fan SettingdB(A) [lower is better]51015202530354040%50%60%70%80%90%100%915.521.326.629.933.336.6
Fan Speed vs Fan SettingRPMFan Speed vs Fan SettingRPM400600800100012001400160040%50%60%70%80%90%100%5967779221060120413541494Fan 16147969421088123613881536Fan 2

Fan Speed at Fixed Noise Levels

Noise LevelPWM (%)Fan 1 (RPM)Fan 2 (RPM)
15 dB(A)49735753
20 dB(A)59884912
25 dB(A)6910311069
30 dB(A)8112171256
35 dB(A)9614491490

AMD System Test Results

Table

ConditionCPU Temperature (°C)CPU Frequency (MHz)CPU Power (W)Overall Performance
20 dB(A)95.35155187.910165
25 dB(A)95.25169190.310334
30 dB(A)94.25176190.410465
35 dB(A)93.05191193.110777
Full fan speed93.05193193.110784

Graphs

CPU Temperature - AMD SystemDegrees Celsius [lower is better]CPU Temperature - AMD SystemDegrees Celsius [lower is better]9393.59494.59595.520 dB(A)25 dB(A)30 dB(A)35 dB(A)Full fan speed95.395.294.29393
CPU Frequency - AMD SystemMHz [higher is better]CPU Frequency - AMD SystemMHz [higher is better]51505160517051805190520020 dB(A)25 dB(A)30 dB(A)35 dB(A)Full fan speed5154.65169.151765190.75193.3
CPU Power - AMD SystemWattsCPU Power - AMD SystemWatts18718818919019119219319420 dB(A)25 dB(A)30 dB(A)35 dB(A)Full fan speed187.9190.3190.4193.1193.1
Overall Performance - AMD SystemScore [higher is better]Overall Performance - AMD SystemScore [higher is better]100001020010400106001080020 dB(A)25 dB(A)30 dB(A)35 dB(A)Full fan speed1016510333.910464.510777.110783.5
All data and graphs included in this test report can be used by any individual on the following conditions:
› It should be mentioned that the test results are provided by Cybenetics
› The link to the original test results document should be provided in any case
