| 115V | 230V | |
| Scheme: ETA-EMI PSU | ![]() |
![]() |
| 115V | 230V | |
![]() |
![]() |
Scheme: LAMBDA PSU |
Outside Validation Scope

| Load | Normal ambient fan · noise · intake | High ambient fan · noise · intake | Noise change |
|---|---|---|---|
| 10% | 0 RPM · <6.0 dB(A) · 37.6 °C | 0 RPM · <6.0 dB(A) · 42.6 °C | fan off in both |
| 20% | 0 RPM · <6.0 dB(A) · 38.9 °C | 0 RPM · <6.0 dB(A) · 42.7 °C | fan off in both |
| 50% | 491 RPM · <6.0 dB(A) · 30.8 °C | 517 RPM · <6.0 dB(A) · 42.2 °C | <6.0 in both |
| 100% | 2336 RPM · 41.8 dB(A) · 30.2 °C | 2739 RPM · 44.5 dB(A) · 46.0 °C | +2.7 dB(A) |
| Load | Normal ambient fan · noise · intake | High ambient fan · noise · intake | Noise change |
|---|---|---|---|
| 10% | 0 RPM · <6.0 dB(A) · 38.0 °C | 0 RPM · <6.0 dB(A) · 51.7 °C | fan off in both |
| 20% | 0 RPM · <6.0 dB(A) · 39.0 °C | 0 RPM · <6.0 dB(A) · 53.9 °C | fan off in both |
| 50% | 511 RPM · <6.0 dB(A) · 30.0 °C | 533 RPM · <6.0 dB(A) · 42.3 °C | <6.0 in both |
| 100% | 2392 RPM · 42.1 dB(A) · 30.7 °C | 2642 RPM · 44.0 dB(A) · 45.4 °C | +1.9 dB(A) |
Informational. Not part of the ETA or LAMBDA rating.
