| 115V | 230V | |
| Scheme: ETA-EMI PSU |  |
 |
| 115V | 230V | |
 |
 |
Scheme: LAMBDA PSU |
Outside Validation Scope
| Product Identification Details | |
| Brand | SAMA |
| Model | GT650W |
| OEM/ODM | RSY |
| Serial Number | |
| Product Specifications | |
| Manufacturer-Provided Information | |
| Rated Voltage (Vrms) | 100-240 |
| Rated Current (Arms) | 10 |
| Rated Frequency (Hz) | 50-60 |
| Rated Power (W) | 650 |
| Operating Temperature (Continuous Full Load) (°C) | |
| Type | ATX12V |
| Cable Design | Fully Modular |
| Warranty | - |
| Cybenetics Measurements | |
| Dimensions (W x H x D) | |
| Weight | |
| Cooling | 120mm Fluid Dynamic Bearing Fan (S1202512L) |
| Semi-Passive Operation | ✗ |
| Cybenetics Testing Information | |
| Lab ID | SM65002570 |
| Date of receipt | Sep 4, 2024 |
| Testing Date | Sep 16, 2024 |
| Report Issued Date | Sep 17, 2024 |
| Engineer Name | - |
| Authorized By the Laboratory Technical Manager | Aristeidis Bitziopoulos |
| Signature | |
| Load | Normal ambient fan · noise · intake | High ambient fan · noise · intake | Noise change |
|---|---|---|---|
| 10% | 970 RPM · 26.3 dB(A) · 30.4 °C | 992 RPM · 26.3 dB(A) · 40.2 °C | +0.0 dB(A) |
| 20% | 974 RPM · 26.4 dB(A) · 30.5 °C | 996 RPM · 26.8 dB(A) · 40.8 °C | +0.4 dB(A) |
| 50% | 980 RPM · 26.2 dB(A) · 30.6 °C | 1571 RPM · 39.3 dB(A) · 42.2 °C | +13.1 dB(A) |
| 100% | 1936 RPM · 43.5 dB(A) · 30.5 °C | 2044 RPM · 44.9 dB(A) · 45.2 °C | +1.4 dB(A) |
| Load | Normal ambient fan · noise · intake | High ambient fan · noise · intake | Noise change |
|---|---|---|---|
| 10% | 973 RPM · 26.4 dB(A) · 30.2 °C | 995 RPM · 26.4 dB(A) · 40.1 °C | +0.0 dB(A) |
| 20% | 976 RPM · 26.2 dB(A) · 30.4 °C | 998 RPM · 26.9 dB(A) · 41.0 °C | +0.7 dB(A) |
| 50% | 982 RPM · 26.0 dB(A) · 30.6 °C | 1636 RPM · 38.4 dB(A) · 42.5 °C | +12.4 dB(A) |
| 100% | 1927 RPM · 43.4 dB(A) · 30.1 °C | 2039 RPM · 44.8 dB(A) · 45.6 °C | +1.4 dB(A) |
Informational. Not part of the ETA or LAMBDA rating.
